Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
FAULT
CODE
MODULE DESCRIPTION POSSIBLE CAUSE SERVICE ACTION
P16C5 ECM
Safety fuel cut
off
activ - Monitoring
level 1
P16C6 ECM
Safety fuel cut off
activ - Monitoring
level 2
P16C7 ECM
Monitoring f
ault due
to throttle valve
plausibility check
Damaged throttle
actuator, da
maged
circuit wires, damaged
connector or damaged
ECM
Check system circuit, perform
closed throttle with B.U.D.S.
Replace throttle actuator, replace ECM.
P16C8 ECM
Monitoring fault
due to exceeding
permitted
throttle
valve position
Damaged throttle
actuator, d
amaged
circuit wires, damaged
connector or damaged
ECM
Check system circuit, perform
closed throttle with B.U.D.S.
Replace throttle actuator, replace ECM.
P16C9 ECM
Monitoring detected
non plausible D.E.S.S.
key state
Damaged D.E.S.S.
key switch
,damaged
circuit wires, damaged
connector or damaged
ECM outpu
tpins
Remove D.E.S.S. key and check
system circuit B-B2.
Refer to th
e Service Manual for
more details.
P2080
ECM
Exhaust temperature
not plausible
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM output
pins
Check for approximately 2280
to 2736 oh
ms at temperature of
19 to 21°C (66 to 70°F) between
system circuits A-H4 and A-J4.
Refer to t
he Service Manual for more
details.
P2081
ECM
Exhaust temperature
sensor fault
Intremittent connection.
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM output
pins
Check for
approximately 2280
to 2736 ohms at temperature of
19 to 21°C (66 to 70°F) between
system c
ircuits A-H4 and A-J4.
Refer to the Service Manual for more
details.
P212C ECM
Electrical lower-range
violation TPS 2
Damaged throttle
actuator, damaged
circui
t wires, damaged
connector or damaged
ECM
Check system circuit, perform
closed throttle with B.U.D.S.
Replace throttle actuator, replace ECM.
P212D
ECM
Electrical upper-range
violation TPS 2
Damaged throttle
actuator, damaged
circu
it wires, damaged
connector or damaged
ECM
Check system circuit, perform
closed throttle with B.U.D.S.
Replace throttle actuator, replace ECM.
P2159
ECM
TAS (
Throttle
Accelerator sensor)
signal not plausible
Damaged sensor,
damaged circuit wires,
damaged connector or
damaged ECM pins
Check system circuits B-E1, B-K1,
B-K3, B-A3, B-B3, B-J3.
Chec
k for 0 volt on sensor connector
pin B & E.
Check for 5 volts on sensor connector
pin A
&D.
Check for 0.5 to 3 volts on sensor
connector pin F and 0.25 to 1.5 on C.
Ref
er to the Service Manual for more
details.
smr2009-029 209
