Section 02 ENGINE

Subsection 09 (COOLING SYSTEM)

smo2009-002-137_a

1. Level between marks when engine is cold

Do not install pressure cap at this time.

Start engine and let run for a maximum of 2 min-

utes. Stop engine and wait 15 minutes to cool

down. Refill tank as necessary.

NOTE: Properly cool exhaust system by installing

a garden hose. Refer to

EXHAUST SYSTEM

sub-

section.

Repeat this run-stop cycle 2 - 3 times until ther-

mostat opens and stop engine.

smr2009-024-003_a

1. This hose becomes hot when thermostat opens

Last,

refill expansion tank and install pressure cap.

When engine has completely cooled down,

recheck coolant level coolant tank and top up if

necessary.

INSPECTION

COOLING SYSTEM LEAK TEST

WARNING

To avoid poten

tial burns, do not remove the

expansion tan

k cap or loosen the ride plate

drain plug if t

he engine is hot.

Remove the deck extension. Refer to

BODY

sub-

section.

Install the

TEST CAP (P/N 529 035 991) on the

coolant expansion tank.

529035991

NOTE: It is not necessary to install a hose pincher

on overflow hose.

Connect t

VACUUM/PRESSURE PUMP (P/N 529

021 800)

o test cap and pressurize system

through c

oolant expansion tank to 90 kPa (13 PSI).

smr2009-024-103_a

1. Vacuum/pressure pump

2. Test cap

Check all hoses, ride plate, engine and oil cooler

for coolant leaks. Spray a soap/water solution and

look for air bubbles.

Check the leak indicator hole if there is oil or

coolant. If so, replace appropriate water pump

shaft seal.

smr2009-024 119
