Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 02 (iCONTROL SYSTEM)
iCONTROL SYSTEM
GENERAL
The iControl (intelligent Control) system consist of
the following systems:
– Intelligent Throttle Control (iTC)
– Intelligent Brake and Reverse (iBR)
– Intelligent Suspension (iS).
The gauge is used with the iControl system to nav-
igate through and select several functions, modes
of operation and change certain settings and sys-
tem parameters using the appropriate handlebar
control s.
smo2009-002-119
INFORMATION CENTER (GAUGE)
3 6 7 8 2 1
45
smo2009-002-200_c
HANDLE
BAR CONTROL S
1. Handlebar
2. Throttle lever
3. iBR lev
er
4. Cruise
5. Engine START/STOP button
6. VTS s (
Variable Trim System)
7. iS s
8. Information center (gauge) control s
For a c
omprehensive and complete description of
the in
formation center, refer to
GAUGE
subsec-
tion i
nthe
ELECTRICAL SYSTEM
section.
iTC (INTELLIGENT THROTTLE
CONTROL)
The iTC is an electronic throttle control system
that includes a cableless throttle control located
on the RH side of handlebar and an electric throt-
tle actuator (ETA) located on the throttle body.
For a comprehensive and complete description of
this system, refer to its subsection in the
FUEL
SYSTEM
section.
sdd2009-0
01-031_a
1. Throttle lever
2. Throttle accelerator sensor (TAS)
sdd2009-001-030_b
1. Throt
tle body
2. Throttle actuator (inside)
iBR (INTELLIGENT BRAKE AND
REVERSE)
The iB
R is a brake and reverse system that is used
to avo
id obstacles, gradually slow down or stop
the w
atercraft by lowering the iBR gate that re-
vert
s the water flow at the outlet of the jet pump
nozz
le.
smr2009-047 177
