Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
– Start engine.
– Check if fault code disappeared.
The electronic system will react differently de-
pending on the fault type. In severe failure, the
engine may not be allowed to be started. In other
cases, the engine will operate in limp home mode
(reduced speed).
Limp Home Mode
When a major component of the EMS or the iBR
is not operating properly the limp home mode will
be set. Engine speed will be limited and therefore
vehicle speed. This mode allows the rider to go
back home which would not be otherwise possi-
ble without this advanced system. LIMP HOME
MODE will be displayed in the information center.
The performance-reduced modes or safety-re-
lated modes allow the rider to go back home
which would not be otherwise possible without
this advanced system.
Major Fault and Vehicle Reaction
The following EMS conditions will trigger a limp
home mode.
ENGINE PRO
BLEM
MAX ALLOWED
RPM
High engine temperature
(from 110°C (230°F))
3000
High exhaust temperature
(from 110°C (230°F))
3000
Low oil pressure
(below 180 - 220 kPa
(26 - 32 P
SI))
2500
The following conditions will trigger a limp home
mode.
iBR PROBLEM SYSTEM BEHAVIOR
iBR gate will be moved
and locked in forward
position (if
possible)
Any active fault code
relatedtotheiBRthat
prevents its
proper
operation
Engine will be set in limp
home mode (re
duced
speed)
The following conditions will stop the suspension.
iS PROBLEM SYSTEM BEHAVIOR
Any active fault code
related to the iS that
prevents i
ts proper
operation
Suspension operation
will be disabled.
It will remain at the
position it was when the
fault code was set.
Indicator Lights and Message Display
Information
Indicator lights (pilot lamps), located in the
speedometer and tachometer indicator, inform
the rider of a selected function, a normal condi-
tion, a system anomaly, or a serious malfunction.
188 smr2009-029
