Section 07 BODY AND HULL
Subsection 03 (HULL)
GENERAL
Verify condition and operation of hinges and latch-
ing mechanisms. Replace any damaged compo-
nents.
During assemb
ly/installation, use torque values
and service pr
oducts as specified in the exploded
views.
Clean threads before applying a threadlocker. Re-
fer to
SELF-LOCKING FASTENERS
and
LOCTITE
APPLICATION
at the beginning of this manual for
complete procedure.
NOTICE
When applyin
g threadlocker prod-
ucts (anaero
bic products), pay attention to
prevent the p
roduct from coming into contact
with ABS pla
stic parts (painted parts). Plastic
parts may de
velop cracks or other damages,
and finishe
d or painted surfaces may become
damaged.
WARNING
Torque wrench tightening specifications
must be strictly adhered to.
Locking devices (e.g.: locking tabs, elastic
stop nuts, self-locking fasteners, cotter pins,
etc.) must be replaced with new ones.
Hoses, ca
bles or locking ties removed during a
procedur
e must be reinstalled as per factory stan-
dards.
PROCEDU
RES
INLET GR
ATE
Inlet Grate Removal
1. Remove i
nlet grate retaining screws using an
impact t
ool and remove inlet grate. Discard the
retaini
ng screws.
smr2009-043-013_a
1. Inlet grate screws
2. Inlet grate
NOTICE
An impact screwdriver should be
used to loosen screws.
Inlet Grate Installation
When installing inlet grate, install NEW screws
with Scotch Grip.
smr2009-043-013_b
1. M8 x 40 s
crew
2. M8 x 20 screws
Follow this sequence referring to the illustration:
1. Hand tighten inlet grate screws., then torque
screws to 35 N•m (26 lbf•ft) as per sequence in
following illustration.
1
2
3
smr2009-043-015_a
INL
ET GRATE TORQUE SEQUENCE
500
smr2009-042
