Section 02 ENGINE
Subsection 04 (SUPERCHARGER)
GENERAL
During assembly/installation, use the torque val-
ues and service products as in the exploded view.
Clean threads
before applying a threadlocker. Re-
fer to
SELF-LO
CKING FASTENERS
and
LOCTITE
APPLICATION
a
t the beginning of this manual for
complete proc
edure.
WARNING
Torque wrench tightening specifications
must be strictly adhered to.
Locking devices (e.g.: locking tabs, elastic
stop nuts, cotter pins, etc.) must be replaced
with new ones.
Hoses, cables or locking ties removed during a
procedure must be reinstalled as per factory stan-
dards.
INSPECTION
SUPERCHARGER INLET
CLEANLINESS
NOTE: A lower than usual maximum RPM at full
throttle might be caused by a dirty supercharger
inlet.
Remove the deck extension. Refer to
BODY
sub-
section for proper procedure.
Remove the air intake silencer. Refer to
AIR IN-
TAKE SYSTEM
subsection.
Remove the air intake silencer support.
smr200
9-020-010_a
1. Air intake silencer support
smr2009-02
0-011_a
MANY PARTS REMOVED FOR CLARITY PURPOSE
1. Support screws
Remove the a
ir inlet hose from supercharger.
smr2009
-020-012_a
1. Air inlet hose
2. Hose clamp
Visuall
y inspect supercharger inlet side for oil, salt
or any ot
her deposits.
smr2006-012-010_a
1. Dirt here
If dirt is found, proceed as follows.
smr2009-020 39
