Clothing

When using the machine, wear close-fitting work clothes,

tough working gloves, ear defenders and non-slip boots with

steel toecaps.

Be extra careful to stay away from rotating parts while working.

Use

Before using the machine, remove all foreign objects from the vicinity. Stones, glass,

branches and similar items can damage the tiller. Also check that bolts on the tiller are

tightened.

Start:

Set the throttle to fully open.

Follow motor start instructions.

Stop:

Set the throttle to minimum gas.

Follow motor stop instructions.

The black handle is used to move the tiller forwards. The red handle is used to move the tiller

backwards. Take care not to operate the tiller in reverse when standing with your back to an

object, for example, a tree or wall. Always exercise extra precaution when backing up or

moving the machine backwards.

The tiller blades pull the machine forwards. In other words, the speed of the machine

depends on how much gas you give it. If you hold the tiller back, the blades dig into the

ground.

If the tiller has a tendency to dig down, there are several things you can do. The right and left

blade set can be changed. This means that the tiller will use the back of the blade to till, and

thus it will not dig down so easily. In addition, side guards can be fitted. This also helps

prevent the tiller from digging down.

The depth skid must always be placed in the top notch if this is the case. See also the section

on adjusting the depth skid.

The tiller's speed is regulated not only by the speed of the engine, but also by the depth skid,

which is situated behind the machine.

Do not till very wet soil, as clods of earth will be formed, and these are difficult to break up.

Dry and hard soil may need to be tilled twice.

The outer blades can be removed if the tiller is to be used between narrow rows of plants and

crops. This reduces the tilling width.

The ground can be tilled in two directions, thus achieving optimum tilling.

Figure 14.

When the engine is running, do not pull the handle for forward speed and the handle

for reverse speed at the same time! This will damage the transmission. Always release
