42 2 5094401 P06-0960 PULLEY, 3-1/2 OD X 25 小滑輪

43 10 5094501 P06-0961 PULLEY, 4-1/2 OD X 25 大滑輪

44 4 5205401-A P06-2129 END CAP, FLATOVAL 橢圓管塞

45 16 5214601-C P06-2135 COVER, PULLEY 152MM DIA 護蓋

46 2 5213101-B P06-2147 Main Frame Foot Pad 腳墊

47 2 5257201-A P06-2203 RUBBER FOOT PAD

橡膠墊

48 16 5217601-A P06-2208 WASHER, RUBBER 19 ID X 25 OD X 3 墊片

49 12 5216301-A P08-0165 SPACER, FLNG 16.2 X 10.2 X 7.5 T帽套管

50 8 5316801-A P08-0168 SPACER, FLANGE T帽套管

51 4 5224001-A P03-1932 SPACER 鐵心

52 4 5224101-A P03-2021 SPACER 鐵心

53 8 RIVET 拉釘

54 1 2005406 BOLT, 3/8-16 X 1-3/4" (45mm) SOCKET HEAD 六角承窩螺絲 3/8" x 1 3/4"L

55 2 2005409 BOLT, 3/8-16 X 2-1/2" (64mm) SOCKET HEAD 六角承窩螺絲 3/8" x 2 1/2"L

56 4 BOLT, 3/8-16 X 6" (152mm) SOCKET HEAD

六角承窩螺絲 3/8"

x 6"L

57 1 5310301-A P04-2996 DAP UPPER CROSS BRACE 連接管

58 1 5317401-A P04-2997 ACCESSORY HOOK ASSEMBLY 掛架片組

59 1 5309801-A P04-2998 DAP CHIN-UP 連接管

60 4 5095701-B P05-1001 ALUMINUM CAP 鋁蓋

61 4 5095601-B P05-1002 COLLAR 固定軸套

62 2 5316101-A P06-2305 HAND GRIP 把手套

63 2 5316201-A P06-2306 HAND GRIP 把手套

64 16 SET SCREW M4x3mmL 止付螺絲

65 6

BOLT, 3/8-16 X

-1/2" (

140

mm) SOCKET HEAD

六角承窩螺絲 3/8"

x 5

1/2"L

66 6 5185201-A P03-2084 SHAFT 套管

67 1 5311001-C P04-3001 CARRIAGE BRACKET 調整片組

68 12 5316501-A P05-1024 ROLLER ROD 滾軸

69 2 P05-1025 SHOULDER BOLT 限位螺絲

70 4 5317601-A P05-1030 SPRING 拉簧

71 4 5311501-A P06-2203 CARRIAGE COVER 橡膠護蓋

72 6 5184901-A P06-2304 ROLLER 塑膠滾輪

73 2 5297801-B P11-0189 ADJUSTMENT PIN 彈簧插銷組

74 2 51704PA-A P20-3203

SSY,

SWIVEL PULLEY HOUSING

滑輪固定片組

75 12 BEARING 6201ZZ 培林

76 1 5310901-C P04-3000 CARRIAGE BRACKET LEFT 左調整片

77 2 5170401-A P04-3003 SWIVEL PULLEY HOUSING 滑輪固定片

78 4 P08-0061 BUSHING 含油軸承

79 2

BOLT, 3/8-16 X

" (

mm) SOCKET HEAD

六角承窩螺絲 3/8"

x 3"L

80 2 5324101-A P02-4482 PLATE 調整片

81 2 5324201-A P04-3002 HEAD PLATE PULLEY HOUSING 滑輪固定片

82 2 P05-0187 PIN 彈簧鞘

83 4 5218401-B P06-2145 BUMPER 橡膠墊

84 2 52102PA-B P10-0777 15LB HEAD PLATE 上片組
