─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Upright Frame 1 27 Aluminium Cap Φ25 2

2 Arm Frame 1 28 Aluminium Ring Φ25 2

3 Right Bottom Frame 1 29 End Plug 2

4 Left Bottom Frame 1 30 Rubber Foot 4

5 Front Standing Frame 1 31 Plug 1

6 Left Standing Frame 1 32 Tapered Roller Bearing 2

7 Cross Frame 1 33 Socket Head Cap Screw M12*155 3

8 Arm Pad Frame 1 34 Socket Head Cap Screw M12*135 4

9 Leg Pad Frame 1 35 Socket Head Cap Screw M12*125 4

10 Footplate Frame 1 36 Socket Head Cap Screw M12*90 4

11 Arm Pad 1 37 Socket Head Cap Screw M12*80 8

12 Leg Pad 1 38 Socket Head Cap Screw M12*35 9

13 Weight Horn Assembly 1 39 Socket Head Cap Screw M12*30 3

14 Weight Plate Storage 2 40 Button Head Cap Screw M10*75 5

15 Aluminum Deck plate 1 41 Flat Head Cap Screw M10*25 6

16 Pivot Plate 1 1 42 Flat Head Cap Screw M12*30 3

17 Pivot Plate 2 1 43 Flat Head Cap Screw M12*50 1

18 Pivot Shaft Φ30 1 44 Nylon lock Nut M12 26

19 Rubber Bumper 1 45 Flat Washer Φ11*Φ20*2 5

20 Domed Aluminium Cap 4 46 Flat Washer Φ13*Φ24*1.5 61

21 Long Weight Horn Sleeve 1 47 Socket Set Screw M8*6 2

22 Weight Horn Sleeve 2 48 Socket Set Screw 10-32*3.2 4

23 Weight Horn Plastic Cap 1 49 Hex key S=10 1

24 Aluminium Grip 2 50 Hex key S=8 1

25 Large Rubber Bumper 1 51 Hex key S=6 1

26 Weight Horn Rubber Donut 2 52 Hex key S=4 1
