─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No. Part Number Description Qty

1 CHFID0100 Frame, Adjustable Seat Pad 1

2 CHFID200 Frame, Back Pad Support 1

3 CHFID0300 Frame Sleeve, Adjustable Seat Pad 1

4 SL70110400 Frame, Seat Pad Support 1

5 SL70110500 Rear Base 1

7 SL70120700 Main Frame 1

8 CHFID0800V1 Frame, Adjustable Back Pad 1

9 IT70110900 Axle Φ25.4*132.5 1

10 SL70111000 Back Pad 1

11 KFAAB1500Y Pop Pin 2

12 SL70013000 Seat Pad 1

13 M02502000 Bushing Φ38*Φ25.4*18 2

14 AXT3S2800 Bushing Φ38*Φ25.4*7.5 2

15 M01402000 Bushing Φ25*Φ12.2*13 6

16 KPSFID2800 Plug 50.8*76.2 1

17 HF1651600A Glide Sleeve 2

19 PBF70001Y Small Grips Φ26*Φ19*80 2

20 KPSFID0700 Nylon Spacer 1

21 TLP-2002100 Bummper 1

22 DP86703101B Wheel 2

23 AT4804000 Spacer 4

24 PBF70003 Grips Φ25*125 1

25 DQ12DHS2A Flat Washer Φ13*Φ24*1.5 14

26 GB9510DHS2 Flat Washer Φ11*Φ20*2 6

27 PNLM10*30*30DHS20 Button Head Cap Screw M10*30 6

28 GB70M12*110DHS20 Socket Head Cap Screw M12*110 3

29 GB70M12*140DHS20 Socket Head Cap Screw M12*140 1

30 GB70M12*135DHS20 Socket Head Cap Screw M12*135 2

31 GB70M12*160DHS20 Socket Head Cap Screw M12*160 1

32 GB70M8*20*20DHS2 Socket Head Cap Screw M8*20 1

33 GB70M8*45DHS20 Socket Head Cap Screw M8*45 2

34 NM8DHS2 Nylon Lock Nut M8 2

35 NM12DHS2 Nylon Lock Nut M12 7

36 GB958DHS2 Flat Washer Φ9*Φ16*1.6 4

40 IF81162000 Foot Pad 3

41 NBS6DHS Hex Key S6 1

42 NBS10DHS Hex Key S10 1
