Voltage Conguration
CPU Load-line Calibration
CPU Load-line Calibration helps prevent CPU voltage droop when the
system is under heavy load.
DRAM Voltage
Use this to select DRAM Voltage. The default value is [Auto].
NB Voltage
Use this to select NB Voltage. The default value is [Auto].
HT Voltage
Use this to select HT Voltage. The default value is [Auto].
CPU VDDA Voltage
Use this to select CPU VDDA Voltage. The default value is [Auto].
PCIE VDDA Voltage
Use this to select PCIE VDDA Voltage. The default value is [Auto].
Would you like to save current setting user defaults?
In this option, you are allowed to load and save three user defaults
according to your own requirements.
