List of Parts

B Centre axle

Ca Twist-up eyecups

Cb Rubber eyecups

D Dioptre adjustment

E Body of the binoculars

F Lens tube

G Central focussing wheel

H Eyepiece

I Objective lens

J Image circle with correctly set

eye distance

Eyepieces for spectacle wearers

Depending on the model, your binoculars are equipped with either twist-up eye-

cups (2a) or rubber eyecups (2b). Since there is a larger distance between the

binocular eyepiece and the pupil for those wearing glasses, both eyecup varie-

ties can be adjusted individually.

Twist-up Eyecups (2a)

Screw in the twist-up eyecups (2a) to use the binoculars while wearing glasses.

If you are not wearing glasses, unscrew the eyecups to achieve the required

distance from the pupils.
