Netis DL4305 Технические характеристики онлайн

Netis DL4305 Технические характеристики онлайн
ADSL2+
Brief:
The netis DL4305 is an All-in-One device that combines the functions of a high speed ADSL modem, a 4-Port
10/100Mbps NAT router and a wireless access point. It is designed to provide end-users with a one-stop solution to
acquiring and sharing high-speed Internet access over a wired/wireless network. Supporting the latest ADSL
standards, the DL4305 brings with it much higher speed than dial-up connections. Complying with the
IEEE 802.11n standard, users will get up to 15X the speed and 5X the range of conventional 11g products. It also
provides some practical functions, such as SNMP, TR-069 and more. With this product, users can now enjoy more
kinds of heavy bandwidth consuming applications like wireless HD video streaming.
Easy Network, Trustable
300Mbps Wireless N
ADSL2+ Modem Router
>3 in 1: ADSL 2/2+ Modem, Wireless N Access Point and 4-Port Router, in a single device
Features:
>Wireless N speed up to 300Mbps
>Easy Setup CD provides quick & hassle-free installation
>Easy wireless security encryption with single WPS button
>2*5dBi external antennas provide extended range for better signal coverage and reception
DL4305
Specifications are subject to change without notice. Netisis a registered trademark of Netis Systems Co., Ltd. Other brands and product names are trademarks or
registered trademarks of their respective holders. No part of the specifications maybe reproduced in any form or by any means or used to make any derivative such
as translation, transformation, or adaptation without permission fromNetis Systems Co., Ltd.
DL4305
300Mbps Wireless N ADSL2+ Modem Router
Topological Graph:
CE, FCC
Others
Certification
Environment
Package
1 *DL4305 1 *Quick Installation Guide 1 * Power Adapter 1* Ethernet Cable 2* RJ11 cable 1* Splitter
Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Specification:
1 * 10/100M Auto MDI/MDIX RJ45 4*RJ11
Hardware
PWR LAN1-LAN4 Internet ADSL WLAN WPS
DC 5V/2A(Output)
WPS Power
Interface
LED
Power Supply
Button
183*125.2*30.72 mm
Dimensions (L x W x H )
IEEE 802.3、IEEE 802.3u
Software
Standards
Data Rate
ADSL Feature
Downstream: Up to 24Mbps Upstream: Up to 1Mbps
Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT)
ITU-T G.992.2(G.Lite)
ITU-T G.992.3
ITU-T G .992.5
ITU-T K.2.1
ATM Forum UNI3.1/4.0 PVC (up to 8PVCs) ATM Adaptation Layer Type 5 (AAL5)
ATM QoS Bridged and routed Ethernet encapsulation
VC and LLC based multiplexing PPP over Ethernet (RFC2516)
PPP over ATM (RFC 2364) IPoA (RFC1577/2225)
ATM / PPP Protocol
Main Feature
DHCP, DHCP relay NAT, Static Routing
VPN (PPTP, L2TP, IPSec) Pass-through PVC/Ethernet Port Mapping
DNS Relay, DDNS IGMP Multicast, IGMP snooping V1/V2
Virtual server, DMZ, ACL (Access Control List) UPnP
Management
Web Based Configuration (HTTP), Remote management, Telnet management, command Line Interface,
TR-069, SNMP, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools
Wireless Standards
IEEE802.11g, 802.11b,802.11n
Frequency Range
2.4-2.4835GHz
Wireless Speed
Up to 300Mbps
Wireless Security
Provides 64/128-bit WEP encryption security and wireless LANACL(Access Control List),WPA-PSK/WPA2-PSK
authentication and TKIP/AES encryption security
Wired
Wireless
Internet
WF 2109-
300Mb s Wireless N USB Adapterp
WF-2118
300Mbps Wireless N PCI Adapter
WF-2116
300Mbps Wireless N USB Adapter
Related products
WF-2109
WF-2116
300Mbps Wireless N ADSL2+ Modem Router
DL4305
2*5dBi
Antenna Type
Wireless Security Power
20dBm
WF-2118
QoS
WPS
3 in1
300Mbps
Easy
Setup
5dBi
