Tunnel

Authentication

Select 802.1x tunnel authentication type from dropdown menu.

Please ask the administrator of the access point you wish to connect to

select a correct tunnel authentication method. This pull down menu is

only available when authentication type you use is 'PEAP', ‘TLS /

Smart Card', or 'TTLS'.

When you use 'EAP-FAST' as authentication type, the protocol setting

is always 'Generic Token Card' and can not be changed. You also need

to select ‘Soft Token’ or ‘Static Password’ as password in ‘ID \

Password’ setting.

’EAP Fast’ authentication type also have a sub-menu to set EAP

fast-specific parameters:

If you need to use protected authentication credential, check ‘Use

protected authentication credential’ box, and click ‘Import’ to

load .pac credential file; to remove a loaded credential file, click

‘Remove’.

Session

Resumption

You can enable or disable session resumption here. If you don’t know

if you should enable session resumption or not, please ask your

802.1x authentication administrator.

ID \ Password

tab

Input 802.1x username (ID) and password and other information if it

is required here. Click ‘Show Password’ to show the password you

typed.

Client

Certification tab

Use this tab to select a local certificate from dropdown menu. If the

access point you wish to connect required a specific client certificate,

the certificate must be installed on your computer, and you can select

the certificate here.

Server

Certification tab

Use this tab to use server-based certification. Please select a CA

(Certificate Authority) from dropdown menu. If intermediate

certificates are allowed, please select ‘Allow intermediate certificates’.

Also, if you need to specify CA server’s name, you can specify it in

‘Server name’ field. You can select ‘Server name must match’, so the
