17
LED Indicator Description
Power
This lights green while the Switch is
receiving power.
Link/Act
A steady green light indicates the
corresponding port is connected and a valid
link is established. This will blink green
when there is activity on the port.
100Mbps/1000Mbps
The speed indicator will light green if the
corresponding port is connected and
operating at 1000Mbps. An amber light
indicates the port is operating at 100Mbps.
If the port is connected (as indicated by the
Link/Act indicator) and the speed indicator
does not light, the port is operating at
10Mbps.
Cable Diagnostic
(during boot up only)
Open or short circuit, or hardware
connectivity problem − 100/1000Mbps LED
blinks amber for 5 seconds
