![Zyxel GS3700-48HP Справочник командного интерфейса онлайн [61/384] 154069](/img/pdf.png)
Zyxel GS3700-48HP Справочник командного интерфейса онлайн [61/384] 154069
![Zyxel GS3700-48HP Справочник командного интерфейса онлайн [61/384] 154069](/views2/1168833/page61/bg3d.png)
Chapter 11 Classifier Commands
Ethernet Switch CLI Reference Guide
61
This example creates a classifier (Class1) for packets which have a source MAC address of
11:22:33:45:67:89 and are received on port 1. You can then use the policy command and the
name Class1 to apply policy rules to this traffic flow. See the policy example in Chapter 54 on
page 235.
sysname# config
sysname(config)# classifier Class1 source-mac 11:22:33:45:67:89 source-port
1
sysname(config)# exit
sysname# show classifier
Index Active Name Rule
1 Yes Class1 SrcMac = 11:22:33:45:67:89; S...
