DGE-550T 100/1000 PCI Adapter
6 Installation
With the wide variety of network architecture in mind, the
instructions for driver
‡
software installation are given as
README files on the DGE-550T Software CD-ROM.
Review the file README in the root directory for an
overview and full installation details; see the README and
referenced instruction files in the subdirectory appropriate
to your network operating system.
A brief overview of the installation details is as follows: As
the DGE-550T is Plug-and-Play compliant, the driver
software should be automatically detected and installed in
PCs running Windows 95, 98, and 2000. After “New
Hardware Found” dialog boxes for “PCI Ethernet
Controller” and “D-Link DGE-550T Gigabit Ethernet
Adapter” are displayed in rapid succession, a “Copying
Files” window, and then an ”Insert Disk” window appear.
The final step is placing the DGE-550T Software CD-ROM
in your CD-ROM drive and then making sure the correct
location is selected. Once this is done the software
installation should be complete.
‡
Check
http://www.dlink.com
for newest release of drivers.
