16
LED
Color
LED Status
Description
Green
The NAS is ready.
Off
All the hard disk drives on the NAS are in
standby mode.
Power
1
Green
Flashes green
The NAS is booting up.
Green
The NAS is on and ready.
LAN
Orang
e
Orange
The disk data is being accessed from the
network.
Flashes orange
The NAS is connected to the network.
10
GbE*
Green
Green
The 10GbE network expansion card is
installed.
Off
No 10GbE network expansion card is
installed.
HDD
Red/
Green
Flashes red
The hard disk is being located
3
(visual
indication of the hard drive location.)
Red
A hard drive read/write error occurs.
Flashes green
The disk data is being accessed.
Green
The hard drive can be accessed.
USB
Blue
Flashes blue
every 0.5 sec
1) A USB device (connected to front USB
port) is being detected.
2) A USB device (connected to front USB
port) is being removed from the NAS.
3) The USB device (connected to the front
USB port) is being accessed.
4) The data is being copied to or from the
external USB or eSATA device.
Blue
A front USB device is detected (after the
device is mounted).
Off
1) No USB device is detected.
