RQTX1246
9
ENGLISH
ENGLISH
9
■
USB
The USB mass storage device or the contents in it cannot be read.
• The format of the USB mass storage device or the contents in it is/are
not compatible with the system.
• USB mass storage devices with storage capacity of more than 32 GB
cannot work in some conditions.
Slow operation of the USB mass storage device.
• Large content size or large memory USB mass storage device takes
longer time to read.
The elapsed time shown is different from the actual play time.
• Transfer the data to another USB mass storage device or backup the
data and reformat the USB mass storage device.
■
Main unit displays
“NO PLAY”
• Examine the content. You can only play supported format.
• This system can read and play up to 255 albums or folders (audio and
non-audio).
“F76” or “F61”
• There is a power supply problem.
“ERROR”
• An incorrect operation was done. Read the instructions and try again.
“NOT MP3/ERROR”
• An unsupported MP3 format. The system will skip that track and play
the next one.
“VBR–”
• The system cannot show the remaining play time for variable bit rate
(VBR) tracks.
“NODEVICE”
• The USB mass storage device is not connected. Examine the
connection.
Memory reset (Initialisation)
When the following situations occur, refer to the instructions below to
reset the memory:
• There is no response when buttons are pressed.
• You want to clear and reset the memory contents.
To reset the memory
1
Disconnect the AC mains lead.
(Wait 3 minutes before you continue with step 2.)
2
While you press and hold [1] on the main unit, connect the
AC mains lead again.
“– – – – – – – –” shows on the display panel.
3
Release [1].
All the settings are set back to the factory preset.
It is necessary to set the memory items again.
Specifications
■
Amplifier section
RMS output power stereo mode
Front Ch (both ch driven)
5 W per channel (6
), 1 kHz, 10% THD
Total RMS stereo mode power 10 W
■
FM/AM tuner, terminals section
Preset station FM 30 stations
AM 15 stations
Frequency modulation (FM)
Frequency range 87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75
(unbalanced)
Amplitude modulation (AM)
Frequency range 522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
Headphones jack
Terminal Stereo, 3.5 mm jack
AUX (rear)
Terminal Stereo, 3.5 mm jack
■
Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 
formatted disc)
MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength 790 nm (CD)
Laser power CLASS 1 (CD)
Audio output (Disc)
Number of channels 2 ch (FL, FR)
FL = Front left channel
FR = Front right channel
■
USB section
USB port
USB Standard USB 2.0 full speed
Media file format support MP3 (
.mp3)
USB device file system FAT 12, FAT 16, FAT 32
USB port power 500 mA (max)
■
Speaker section
Type 1 way, 1 speaker system (bass reflex)
Speaker unit(s)
Full range 8 cm cone type
Impedance 6
Frequency range 60 Hz to 25 kHz (–16 dB)
90 Hz to 22 kHz (–10 dB)
■
General
Power supply AC 220 to 240 V, 50 Hz
Power consumption 12 W
Dimensions (W x H x D) 400 mm x 221 mm x 110 mm
[D = 69 mm (min)]
Mass 2.0 kg
Operating temperature range 0°C to +40°C
Operating humidity range 35% to 80% RH (no condensation)
Power consumption in standby mode 0.2 W (approximate)
Note:
1) Specifications are subject to change without notice.
Mass and dimensions are approximate.
2) Total harmonic distortion is measured by the digital spectrum analyzer.
Maintenance
To clean this system, wipe with a soft, dry cloth.
• Never use alcohol, paint thinner or benzine to clean this system.
• Before using chemically treated cloth, read the instructions that came
with the cloth carefully.
SC-HC15_EP_01en.indd 9SC-HC15_EP_01en.indd 9 3/11/2011 5:24:21 PM3/11/2011 5:24:21 PM
