TL-WA801ND 300Mbps Wireless N Access Point User Guide

¾ Status - Select a status for this entry, either Enabled or Disabled.

To set up an entry, follow these instructions:

First, you must decide whether the unspecified wireless stations can access the device or not. If

you desire that the unspecified wireless stations can access the device, please select the radio

button Deny the stations specified by any enabled entries in the list to access, otherwise,

select the radio button Allow the stations specified by any enabled entries in the list to

access.

To add a MAC Address Filtering entry, follow these instructions:

1. Enter the appropriate MAC Address into the MAC Address field. The format of the MAC

Address is XX-XX-XX-XX-XX-XX (X is any hexadecimal digit). For example:

00-0A-EB-B0-00-0B.

2. Enter a simple description of the wireless station in the Description field. For example:

Wireless station A.

3. Select Enabled or Disabled for this entry on the Status pull-down list.

4. Click the Save button to save this entry.

To add additional entries, repeat steps 1-4.

To modify or delete an existing entry:

1. Click the Modify in the entry you want to modify. If you want to delete the entry, click the

Delete.

2. Modify the information.

3. Click the Save button.

Click the Enable All button to make all entries enabled

Click the Disabled All button to make all entries disabled.

Click the Delete All button to delete all entries

Click the Next button to go to the next page and click the Previous button to return to the previous

page.

For example: If you desire that the wireless station A with MAC address 00-0A-EB-00- 07-BE is

able to access the device, while all other wireless stations cannot access the device, you should

configure the Wireless MAC Address Filtering list by following these steps:

1. Click the Enable button to enable this function.

2. Select the radio button: Allow the stations specified by any enabled entries in the list to

access for Filtering Rules.

3. Delete all or disable all entries if there are any entries already.

4. Click the Add New... button and enter the MAC address 00-0A-EB-00-07-BE in the MAC

Address field, enter Wireless Station A in the Description field and select Enabled in the

Status pull-down list. Click the Save button.

The filtering rules that configured should be similar to the following list:
