8. OCTAVE CHANGE

This function allows you to shift the pitch up to two octaves higher or one lower.

8-1 Press the OCTAVE switch. The LED starts to flash showing the current OCTAVE value.

8-2 Press the “+” or “-” switch and the pitch will be shifted one octave higher or lower.

* Press + and - switches simultaneously to reset the pitch to the default value.

Note: if the “+” or “-” switch is not pressed for 5 seconds, the LED will return to show the PROGRAM CHANGE number.

9. Sending a PROGRAM CHANGE number

Using the PROGRAM switch and the numeric keys, you can send any MIDI PROGRAM CHANGE from 0-127.

9-1 Press the PROGRAM switch. The LED starts to flash showing the current PROGRAM number.

9-2 Press the numeric keys to change the PROGRAM CHANGE number. You can also use the “+” or “-” keys to change

the value.

Note: * if you don’t do anything for 5 seconds the LED stops flashing and shows the current PROGRAM CHANGE number.

* if the number you press is larger than 127, it will return to the previous PROGRAM CHANGE number.

10. Sending BANK MSB and LSB message

You can send any value of MSB or LSB from 0-127.

10-1 Press the CHANNEL and PROGRAM switches simultaneously. The LED starts to flash showing the current value

of the LSB. Press the numeric keys to change the LSB value. You can also use the “+” or “-” switches to change the value.

10-2 Press the PROGRAM and MEMORY switches simultaneously. The LED starts to flash showing the current value of

the MSB. Press numeric keys to change the MSB value. You can also use the “+” or “-” switches to change the value.

Note: * if you don’t do anything for 5 seconds the LED stops flashing and shows the current PROGRAM CHANGE number.

* if the number you input is over 127, it will return to the previous LSB or MSB value.

11. PROGRAM & BANK CHANGE MEMORY

You can assign a selected PROGRAM CHANGE as well as a BANK LSB and a BANK MSB to one of six numeric keys (0-5).

Once stored, simply pressing one of the numeric keys will send the desired PROGRAM and BANK CHANGES.

11-1 Select the desired PROGRAM CHANGE, BANK LSB and MSB. Please refer to respective chapters for information

on how to do this.

11-2 Press the MEMORY switch. The LED starts to flash.

11-3 Press the numeric key (from 0 to 5) you wish to assign the data to. The PROGRAM and BANK CHANGE

information is stored on the selected numeric key until the unit is powered off.
