V2416 Linux User's Manual Software Configuration
2-4
Section “Screen”
Identifier “Screen0”
Device “Intel Corporation Mobile 945GM/GMS, 943/940GML Express
Integrated Graphics Controller”
Monitor “TMDS-1”
EndSection
In the above configuration, the VGA port and LVDS port are ignored.
c. To display on both a VGA port and DVI port, you only need to ignore the LVDS monitor section.
Section “Device”
Identifier “Intel Corporation Mobile 945GM/GMS, 943/940GML Express
Integrated Graphics Controller”
Driver “intel”
Option “monitor-VGA” “VGA”
Option “monitor-TMDS-1” “TMDS-1”
Option “monitor-LVDS” “LVDS”
EndSection
Section “Monitor”
Identifier “VGA”
EndSection
Section “Monitor”
Identifier “TMDS-1”
EndSection
Section “Monitor”
Identifier “LVDS”
Option “Ignore” “true”
EndSection
Section “Screen”
Identifier “Screen0”
Device “Intel Corporation Mobile 945GM/GMS, 943/940GML Express
Integrated Graphics Controller”
Monitor “VGA”
EndSection
2. At this point, you can issue the following command to test your setting:
MOXA:~# /etc/init.d/gdm start
3. To log in from a desktop environment, issue the following command:
MOXA:~# mv /etc/rc2.d/N30gdm /etc/rc2.d/S30gdm
4. Reboot the Moxa embedded computer to use the desktop environment.
