IV. Before first use

The installation of roller-legs

Follow the instruction guide to install properly the

roller-legs. Join the first roller-leg and the axe as

shown in the picture (figure 3).

• Join the second roller-leg (figure 2).

• Turn over the radiator to have access to bottom panel.

Install the bracket (figure 5).

• Join together the bracket and the roller-leg axe (figure

6 and 7).

• Screw the nut tight as shown in picture 7.

• Turn back the radiator. Make sure that roller-legs are

screwed tightly (figure 8).

• Push slightly the front leg to install. Use the screw to

join it tightly (figure 9).

Note!

The radiator should always be placed in vertical position to reduce the risk of overheating, fire or electric

shock.

V. The radiator operation

Make sure that the horizontal surface on which the radiator is placed is firm and steady and there

are no any inflammable objects in the distance of 1 metre.

•

Before plugging the device in outlet, please make sure, that the power control is in the “0”OFF position

and the thermostat control in the “MIN” position.

•

Please rotate clockwise the thermostat controller up to «MAX» position. Use the power regulator to

choose the required temperature: I position – low power, II position – medium power and III position –

high power.

Figure 3

Figure 4

Figure 5

Figure

Fig. 8

Fig. 7

Fig. 9
