Operation

1. Open battery compartment cover. Insert 4 batteries with proper polarity into the holder. Contacts of the holder (batteries)

or Li-batteries must coincide with contacts of the battery compartment. Close the battery cover.

2. Place the instrument on the tripod or oor. When using tripod, place the instrument on the tripod and screw the centering

screw into the center hole.

3. Switch On the instrument by rotating the switch 2 counterclockwise until its clicking position. Green LED will ash. If the

battery power is low, green color of the indicator will be changed into red.

4. The instrument works in slope mode in the rst position of the switch (X). It is possible to project laser lines at any angle.

In the position ON the pendulum will be unlocked and laser lines will be automatically self-leveled.

5. If there is a sound signal and laser lines begin to blink while switching on the instrument, that means that the instrument is

out of range more than ±3°. Adjust the position of the instrument by means of the bubble level with the help of legs or tripod.

6. Aim the down point on the required point on the oor. Rotate the upper part of the instrument to adjust vertical lines.

Then adjust the position of the instrument with the help of ne adjustment screw.

7. Laser level has several operating modes. Press button 1 to select laser lines. Variants of projections:

- horizontal beam and down point;

- horizontal beam and vertical beam, down point;

- horizontal beam and 3 vertical beams, down point.

- orizontal beam and 4 vertical beams, down point.
