MEASUREMENT FOUNDATION

INSTRUMENT SINSTRUMENT S

Operation

INSERTING/REPLACING THE BATTERY

Use only 9Vbattery. Insert the battery into the battery compartment (12) in accordance with the symbols in the battery com-

partment. Remove the batteries if the unit will not be used for a long period. The battery can be corroded or discharged over

long periods.

SWITCHING ON AND OFF

Protect the measuring tool against moisture and direct sun irradiation. Before switching the measuring tool on, make sure that

the sensor area 8 is dry. If required, wipe the measuring tool dry using a cloth.

The object to be measured Depth of detection Accuracy of detection

Rebar/copper tube ø 20 8 cm/6 cm

±1 cm

ø 16 7 cm/6 cm

ø 12 6 cm/5 cm

ø 6 5 cm/5 cm

Live wire and cable 5 cm

Wood Wooden beam 2 cm

Wooden batten 2 cm

Detection performance
