- 11 -
Hardware Installation
Multi-Graphics
Technology
Support for 3-Way/2-Way AMD CrossFire
™
and 2-Way NVIDIA
®
SLI
™
Technology
Storage Interface Chipset:
- 1 x M.2 PCIe connector
- 1 x SATA Express connector
- 6xSATA6Gb/sconnectors(SATA30~5)
(M.2,SATAExpress,andSATA34/5connectorscanonlybeusedoneatatime.
TheSATA34/5connectorswillbecomeunavailablewhenanM.2SSDisinstalled.)
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
USB Chipset:
- 6xUSB3.0/2.0ports(4portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
- 8xUSB2.0/1.1ports(4portsonthebackpanel,4portsavailablethrough
theinternalUSBheaders)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x M.2 PCIe connector
1 x SATA Express connector
6 x SATA 6Gb/s connectors
1 x CPU fan header
1xwatercoolingfanheader(CPU_OPT)
3 x system fan headers
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.0/2.0 header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x Clear CMOS jumper
1xTrustedPlatformModule(TPM)header
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x optical S/PDIF Out connector
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
4 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
5xaudiojacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In,
LineOut,MicIn)
I/O Controller iTE
®
I/O Controller Chip
