- 12 -

particles suspended in the air, therefore it is subject to clogging

with variable frequency according to the use of the appliance.

- To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease filters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

- After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•Theactivecarbonfilters are used to purify the air that is

sent back into the room and its function is to mitigate the

unpleasant odours produced by cooking.

- The non-regenerable active carbon filters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease filter is cleaned.

- Regenerable active charcoal filters must be washed by hand,

with non abrasive neutral detergents, or in the dishwasher at

a maximum temperature of 65°C (the washing cycle must be

complete without dishware). Remove excess water without

damaging the filter, remove the plastic parts, and let the

mat dry in the oven for at least 15 minutes approximately at

a maximum temperature of 100°C. To keep the regenerable

charcoal filter functioning efficient this operation must be

repeated every 2 months. These must be replaced at least

every 3 years or when the mat is damaged.

•Beforeremountingtheanti-greasefiltersandtheregen-

erable active charcoal filters it is important that they are

completely dry.

•Cleanthehoodfrequently,bothinternallyandexternally,

using a cloth dampened with denatured alcohol or neutral

liquid detergents that are non abrasive.

• The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system significantly decreases

the average duration of the bulbs.

• If the appliance is equipped with courtesy lights it is possible

to use them for general room lighting for a prolonged amount

of time.

•Attention: the non compliance with the hood cleaning

warnings and with the replacement and cleaning of the filters

entails risk of fires. One therefore recommends keeping to the

suggested instructions.

•Replacinghalogenlightbulbs(Fig.11A):

To replace the halogen light bulbs B, remove the glass pane

C using a lever action on the relevant cracks. Replace the bulbs

with new ones of the same type. Caution: do not touch the

light bulb with bare hands.

•ReplacingLEDlamps(Fig.11B):

If the appliance version is with LED lamps, the intervention of

a specialised technician is necessary to replace them.

•Commands(Fig.12):

NOTE: with this command it is also possible to control the ap-

pliance using a remote control, to be requested as an accessory.

A Button = Switches the hood on/off. The equipment switches

on at the 1st speed.

B Button = Decreases motor speed.

C Display = Shows the selected motor speed and timer acti-

vation/intense speed/filter warning.

D Button = Increases motor speed.

Pressing the 4th speed button engages the intense function

for 6 minutes, then the equipment goes back to working at

the speed at which it was activated. During this function, the

number 4 flashes on the display.

- If you wish to deactivate the function before the 6 minutes,

press the B button.

Attention! Some models only work up to the 3rd speed and,

therefore, do not have the intense function.

E Button = Pressing this button activates the Timer function

even with any of the 1-2-3 speeds engaged (except the Intense

function speed). When the Timer function is active, the set

speed must flash on the display when the timer is activated.

After 15 minutes, at the end of the countdown, the hood

switches off (motor and any lights remain on).

If the intense speed is engaged, the Timer cannot be activated.

- If you wish to deactivate the function before the 15 minutes,

press the E button.

F Button = Switches the lights on/off.

•Anti-grease/activecharcoalfilterssaturation:

- After 30 h of operation, when the C display flashes, alternating

the working speed with the letter F (i.e. 2 and F), this means

that you need to wash the anti grease filters.

- After 120 h of operation, when the C display flashes, alterna-

ting the working speed with the letters C/F (i.e. 2 and C/F), this

means that you need to wash or replace the charcoal filters.

- Once you have repositioned the clean filter, you need to reset

the electronic memory with the hood on, pressing the B button

for about 3 seconds.

After that time, the letter E appears on the display (reset

confirmed) and the hood switches off.

•Mechanicalcontrols(Fig.13):the symbols are as follows:

A= LIGHT / ON-OFF key

B= OFF /FIRST SPEED key

C= SECOND SPEED key

D = THIRD SPEED key

If the hood is shut o at rst, second or third speed, when

it is turned back on, it will start at the same speed it was in

when switched o.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY

FOR EVENTUAL DAMAGES CAUSED BY BREACHING THE

ABOVE WARNINGS.
