MEASUREMENT FOUNDATION

INSTRUMENTS

WallScanner 120 Prof

In rear cases the detector can’t detect examined object, because the sensor area and type plate are solid and dirty. Just clean the

measuring tool with dry and soft cloth and restart the measuring procedure.

Scanning for “live” wires

This mode is suitable for detecting “live” conductors (110-230V). Press button 8 to activate Charged wire mode. Illuminated

ring and indicator above button 8 light up green. When a live conductor is detected, indication f appears on the display. Move

the detector above the measuring area several times to detect live wires. When the measuring tool is very close to the conductor,



Under certain condition (such as below metal surfaces or behind suefaces with high water content) “live” conductors cannot

be securely detected.



on the wall next to the measuring tool, in order to remove the static electricity.

Temperature control

The detector is equipped with a temperature control indicator . When the temperature control inducator lights up, the mea-



allow it to adjust to the ambient temperature before switching it on again.

Operating Instructions

In accordance with the principles of tool operation, the measuring values can be impaired through certain ambient


