Detector

1. On/Off button

2. Signal LEDs

3. Bubble level

4. Sensitive element

5. Sound Off button

6. Clamp on the staff

7. Dynamic loudspeaker

Application of the detector

Application of the detector is a decisive advantage when

working outside in sunny weather. Press button (3) to

switch on the detector mode. Open the battery cover and

insert the battery into the detector. Press On/Off button to

switch on the detector.

Bring the receiver to the place of beam location. When

laser beam will be on the sensitive element, there will be

sound alarm and one of the LEDs will ash. LED will show

the direction for the receiver for beam detection. Move the

receiver until you will hear continious sound alarm and

middle signal LED will ash. With the help of bubble level

check the leveling of the receiver housing. Mark the sur-

face. Place the detector on the staff with the help of clamp.
