English | 132 610 A15 120 • 25.11.09
Technical Data
Assembly
Inserting/Replacing the Battery
Using alkali-manganese or NiMH batteries is recom-
mended for operation of the measuring tool.
LED 8 begins to flash red when the batteries become
empty. When LED 8 continuously lights up red, the
measuring tool will switch off soon.
– Open the battery compartment 5.
– When inserting the battery, pay attention to the
correct polarity according to the representation on
the inside of the battery compartment.
– Always replace all batteries at the same time. Only
use batteries from one brand and with the identical
capacity.
f Remove the batteries from the measuring
tool when not using it for extended periods.
When storing for extended periods, the batteries
can corrode and discharge themselves.
Operation
Initial Operation
f Protect the measuring tool against moisture
and direct sun light.
f Do not subject the measuring tool to
extreme temperatures or variations in tem-
perature. As an example, do not leave it in vehi-
cles for longer periods. In case of large variations
in temperature, allow the measuring tool to adjust
to the ambient temperature before putting it into
operation. In case of extreme temperatures or var-
iations in temperature, the accuracy of the measur-
ing tool can be impaired.
f Avoid heavy impacts or falling down of the
measuring tool. If the measuring tool has been
exposed to extreme conditions, you should always
check the accuracy of the measuring tool before
continuing your work (see “Accuracy Check of the
Measuring Tool”, page 14).
Starting and Stopping
For switching on the measuring tool, briefly press
the On/Off button 2. Immediately after switching on,
the measuring tool sends two vertical laser beams out
of the exit openings 4.
To switch off the measuring tool, press the On/Off
button 2 approx. 2 seconds until LED 8 and the LED
for hand-receiver mode 9 flash rapidly.
Downward Plumb Point
When the measuring tool is switched on, briefly press
On/Off button 2 to switch the downward plumb point
on.
Selecting the Operating Mode (see figure A)
Pressing operating mode button 3:
Hand-receiver Mode
Press the hand-receiver mode button 1. The hand-
receiver mode LED 9 lights up.
Note: Hand-receiver mode is switched off automati-
cally when horizontal and vertical lines are switched
on at the same time, in order to avoid reception errors.
Cross-line Laser XLP-34
Article number F 034 K63 800
Working outdoors z
Working indoors z
Plumb beam, downward z
Laser cross on ceiling z
Individually selectable, visible laser
lines 3
Working range
– without laser receiver, approx.
– with laser receiver, approx.
30 m
55 m
Levelling duration, typically ≤15s
Self-levelling range, typically ± 3°
Laser class 2M
Laser type 635 nm,
<1 mW
Measuring accuracy
–
Horizontal and vertical lines over 1 m
– Plumb beam, upward, over 1 m
– Plumb beam, downward, over 1 m
– 90° vertical beam over 1 m
± 0.2 mm
± 0.6 mm
± 0.3 mm
± 0.2 mm
Batteries (alkali-manganese)
Batteries (NiMH)
3x1.5V (AA)
3x1.2V (AA)
Weight according to
EPTA-Procedure 01/2003 0.7 kg
Degree of protection IP 54 (dust and
splash water
protected)
1 x Activates the horizontal line
2 x Activates the horizontal and vertical lines
3 x Manual mode, all lines are visible.
The hand-receiver mode LED flashes slowly in
manual mode, which does not mean that hand-
receiver mode is active. The levelling mode is
deactivated and was stopped in the position in
which it was when activating manual mode.
4 x Automatic operation, vertical lines active
