user manual
CROSS
LINE LASER
EN
user manual
CROSS
LINE LASER
EN
XLiner Duo/Combo 360 XLiner Duo/Combo 360
OPERATION
Before start operation remove the battery cover, insert the batteries,
observing correct polarity. Put battery cover back.
Use AA alkaline batteries only, all batteries should be of the same type
and brand with the same charge level. Replace batteries if battery
charge level indicator starts flashing red while operation.
Place the laser level on a firm and stable surface or a tripod.
Move compensator lock to choose necessary operating mode:
1) Automatic levelling:
Move lever lock to ON position .
Compensator is unlocked. Power indicator becomes red. If the laser
level is out of the range of automatic compensation laser lines flash.
Short press button to switch on necessary laser planes.
Short press button to switch on/off pulse mode that allows
working with laser receiver. In this mode pulse mode indicator will
turn red. To switch the laser level off move compensator lock to locked
position .
2) Locked compensator, to build inclined planes and lines:
Move compensator lock to OFF position . Compensator is locked.
Power indicator becomes red. Press and hold button
during 3 seconds to switch the laser level on.
Short press button to switch on necessary laser planes.
Activated laser lines flash every 5 seconds in this mode.
TECHINCAL SPECIFICATIONS
Working range/with receiver 30 m/100 m
Self-levelling accuracy ±0,2 mm/m
Self-levelling range ± 4°
Continuous working time >8 hours
Operating temperature -10°C ... +50°C
Storage temperature -20°C ... +70°C
Relative humidity 90%
Protection rating IP54
Tripod mounting thread 1/4’’ and 5/8’’
Laser type Class II 635 nm < 1 mW
Power supply 4 х 1.5V LR6 alkaline (AA)
Dimensions 119x62x115 mm
Weight 0,445 kg
SET
Cross line laser – 1 pcs.
Carry bag – 1 pcs.
Batteries (АА) – 4 pcs.
User manual – 1 pc.
