should always be kept under control in order to improve

working conditions and ensure safety.

ELECTRICAL CONNECTION

Before connecting the tool to the mains make sure that

it complies with the standard regulations of the country in

question, and that the voltage and frequency correspond to

the details on the data plate.When using extension leads,

make sure that cable cross-section conforms to the length

of the lead. When using a wind-up extension make sure

that is completely unwound so as to avoid overheating.

ATTENTION! - The switch on this tool is tted with a

locking device, allowing the tool to be operated for long

periods of time without interruptions. Before inserting

the plug into the socket, check that the switch is in the

unlocked position. When the tool is not to be used for

long periods remember to leave the switch device in

the unlocked position.

PLACE OF WORK

The tool that you have purchased is a portable

electric power tool. Only one user should operate this tool,

given its shape, weight and maneuverability. Normal use

requires that both of the operator’s hands are rmly kept

on the machine and, under all circumstances, away from

the applied tool.5The tool is already regulated according

to standard parameters by the constructor when supplied.

If necessary oscillation and speed adjustments can be

carried out on the model.

OSCILLATION REGULATION

With this movement, during the working stroke, the

blade is pressed against work piece, during the return

stroke the blade is detached from the material in order to

facilitate the discharging of chips and reduce overheating.

The regulation of oscillatory movements can be carried out

whilst the machine is running: Switching from position “0”

to position “III” is by means of the lever L. In order to obtain

maximum working speed and the best results on any type

of material, the appropriate oscillation should be applied.-

For wood and soft synthetic material, maximum oscillation

is required, therefore the regulator should be set at position

“III”.- For steel and hard materials, the blade should not

be forced against the material, therefore the oscillation

should be at minimum, with the regulator be set at position

“0”. - For materials with intermediate hardness, such as

aluminium or hard wood, positions “I” or “II” should be

used, after the appropriate tests have been carried out. The

values supplied are approximate and can vary according

to the thickness, hardness and the ber direction of the

material and blade condition.

SPEED REGULATION( JS85/701VE, JS85/701VE)

In order to improve the machine performance, and

provide maximum working efciency on all types of material,

use the saw model with electronic speed control.

The orange knurled knob E (Fig.1) is mounted on

the body of the machine and is marked with numbers

from 1 to 6.Minimum speed is at position 1 and the speed

progressively increases to max. speed at position 6. The

following speeds are advised: Low speed for cutting glass,

ceramics, metal. Average speed for cutting plastic, pressed

or compensated materials. High speed for cutting hard

wood, soft wood and masonite panels. Carefully choose

the ideal speed for the work that has to be performed by

carrying out preliminary tests.

REGULATION OF SUPPORT BASE

Angled cuts of up to 45° can be performed. In order to

carry out this operation proceed as follows:

- Overturn the machine

- Using an Allen wrench, loosen the athead screw

which holds the base onto the head of the machine.

- Adjust to the desired angle, with the aid of the

graduated scale.

- Re-tighten the athead screw.

OPERATION AND USE

Felisatti jig saws are particularly sturdy and resistant

machines; extremely versatile and maneuverable, ideal for

all continuous cutting work with wood, aluminum, plastic,

steel, etc.

1. STARTING(Fig.1)

JS120/710VE

Push the key forwards until it locks into position

(direction I), in this position the switch is locked in “ON”.

Attention: to unlock the switch, press the orange key

towards the position “0”.

JS85/701, JS85/701VE (Fig.2)

Press the switch key, to lock it in ON, activate the lock

push button located next to the switch.

ATTENTION! In order to unlock the switch, fully press

the switch key - in this manner the lock push button

will trip automatically.

2. HANDGRIP

JS120/710VE (Fig.1)

The grip-shaped machine body allows the tool to be

perfectly guided, the knob handgrip, located on the head,

completes the tool governability.

ATTENTION! During working operations both hands

must be kept rmly on the machine.

JS85/701, JS85/701VE (Fig.2)

These machines are tted with “atiron” shaped

bodies, providing perfect grip and excellent balance

under all working conditions, resulting in incomparable

maneuverability.

ATTENTION! Given the special shape of the body,

these machines can be operated with only one hand,

but for reasons of safety it is strongly advised to keep

both hands on the machine during use.

HOLLOW WORK PIECES

A hole must be drilled in the material, in order to

provide a starting point for the saw.

The saw blade can be directly inserted into the

material (only for wood work pieces), but this operation

should only be performed by operators with considerable

work experience and with the exclusive use of short

blades.

With the machine running, the saw blade should be

rested on the work piece at an angle of 55°-60° in relation

to the front edge of the base, it should then be pressed,

slowly and carefully, onto the material.

The rst phase of the operation should be undertaken

with great care: sudden counter-strokes and overloads

during contact between the blade and work piece, or

excessively rapid penetration of the material, can provoke

blade breakage.

Penetration should only be carried out at maximum
