TECHNICAL DATA

Milling machine RF62/2200VE

bsorbed powe

W 2200

No load speed rpm 11800-21000

 of milling cutter attachment

mm 12

Lengthwise travel mm 0-67

 maximum of milling cutter

mm 60

Machine weight (without accessories) kg 5.6

Total machine height mm 305

The instructions contained in this manual must be strictly

followed, it should be carefully read and kept close at

hand to use when carrying out maintenance on the

indicated parts.

If the machine is used carefully and normal maintenance

is carried out, it will work for a long time.

The functions and use of the tool you have bought shall

be only those described in this manual. Any other use

of the tool is strictly forbidden.

ILUSTRATIONS

DESCRIPTION (See figures)

A ON/OFF switch lever (Fig.2 and Fig.5)

B Spindle lock of shaft (Fig.1)

C Depth adjustment handle (Fig.1)

D Clip fixing nut (Fig.5)

E Depth stop (Fig.1)

F Stepped stop (Fig.1)

G Locking button (Fig.1)

H Fixing lever (Fig.2 and Fig.5)

I Side stop (Fig.2)

J Transparent frontal protection (Fig.1)

K Dust suction adapter (Fig.5 and Fig.6)

L Speed adjustment (Fig.2)

M Depth adjustment scale (Fig.1)

N Speed adjustment scale (Fig.2)

O Grips (Fig.1 and Fig. 2)

P Base plate (Fig.1)

Q Sliding plate (Fig.3 and Fig.5)

R Wing screw for dust suction adapter (Fig.6)

S Strip stop (Fig.2)

T Parallel stop fine adjustment (Fig.3)

U Copier bushing (Fig.3)

V Wing screw (Fig.5 and Fig.6)

EQUIPMENT

- Side stop

- Clip, 1/2” and 1/4”

- Fixed spanner, 22 mm and 8 mm

- Transparent guard

- Dust suction adapter

- Copier bushing

- Operating instructions

- Safety instructions

- Warranty

SAFETY INSTRUCTIONS

 See “Safety Instructions” enclosed manual, supplied

together with this instruction manual.

 WARNING! The dust produced when milling asbestos

and/or silica stone materials is dangerous to health.

Follow the insurance company’s safety instructions

regarding the responsibility of employees.

 For your personal safety, always connect the machine

to a mains supply by a differential and thermal cut-out

switch, in accordance with regulations on low-voltage

wiring sitemaps.

 Do not perforate the machine casing, as this would

destroy the protective insulation (use adhesive labels).

 Always unplug the machine before doing any work on it.

 Always stop the machine by switching it off, not by

unplugging it.

 WARNING! Before each use, inspect the plug and

lead. Should they need replacing, have this done by an

official service centre. Only plug the machine in when it

is switched off.

 Always keep the lead out of the machine’s working

area.

 Only plug the machine in when it is switched off.

 Do not allow the machine to get wet, nor should it be

used in wet environments.

 When using the machine, always wear safety goggles,

gloves and non-slip footwear, and it is advisable to

wear ear protection.

 Check for correct piece fixing before commencing any

operation.

 Only milling heads with acceptable revolutions that are

at least the same as the maximum off-load revolutions

of the machine should be used.

 The milling head shaft diameter should match the

inside diameter of the tool-holder (locking clip).

 It should be ensured that the milling head is firmly held

in place before the machine is operated.

 The clip-carrier shaft support lever must only be oper-

ated when the machine is stopped.

 The milling head should only be brought into contact

with the work-piece after it has been switched on.

 The machine must be firmly held by the grips. Other-

wise the recoil produced could cause the machine to

work imprecisely or even dangerously.

 Hold the machine firmly in both hands and in a stable

position.

 During use, it should be ensured that the milling head

is in the centre of the copy bushing in order to prevent

any personal injury or damages to the work-piece.

 The milling machine must never be used on metal

objects, such as nails and screws.

 Hand must be kept clear of the milling machine while it

is operating.
