7
TECHNICAL DATA
Read the operating instructions
Protection category II power tool; double
insulated
In accordance with essential applicable safety
standards of European directives
Wear eye protection
Wear ear protection
The instructions contained in this manual must be
strictly followed, it should be carefully read and kept close
at hand to use when carrying out maintenance on the
indicated parts.
If the machine is used carefully and normal
maintenance is carried out, it will work well for a long time.
The functions and use of the tool you have bought
shall be only those described in this manual. Any other
use of the tool is strictly forbidden.
ILLUSTRATIONS
DESCRIPTION (See gures)
1 On/Off switch (g.1)
2 Spindle lock button (g.1)
3 Locking screw for auxiliary-handle holder (g.1)
4 Chaser rollers (g.1)
5 Auxiliary handle (g.1) (antivibrational for
SD230/2600E)
6 Protection guard with cutting guide (g.1)
7 Vacuum connection (g.1)
8 Rear handle turning button (g.1)
9 Rear handle (g.1)
10 Screw (g.2)
11 Clamping lever for depth stop adjustment (g.2)
12 Cutting-depth scale (g.2)
13 Cover of protection guard (g.2)
EQUIPMENT
- Wall chaser
- Two diamond cutting discs
- Spacer discs (6mm - 4pcs, 4mm - 3 pcs)
- Clamping nut
- Spanner wrench
- Operating instructions with Safety instructions
- Warranty
BRIEF DESCRIPTION
In conjunction with a vacuum cleaner and with rm
support of the cutting guide, the machine is intended to
cut or slot mainly mineral materials such as reinforced
concrete, brickwork and road surfaces without the use of
water.
BEFORE USING THIS TOOL
WARNING! Always disconnect the plug from the
socket before doing any work on the machine.
1. Dust extraction
Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one’s health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections
of the user or bystanders. Certain dusts, such as oak or
beech dust, are considered as carcinogenic, especially in
connection with wood-treatment additives (chromate, wood
preservative). Materials containing asbestos may only be
worked by specialists.
– Use dust extraction whenever possible.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 lterclass respirator.
Observe the relevant regulations in your country for
the materials to be worked.
The vacuum cleaner must be approved for the
extraction of masonry dust. FELISATTI provides suitable
vacuum cleaners.
The machine can be plugged directly into the
receptacle of a FELISATTI vacuum cleaner with remote
starting control. The vacuum cleaner starts automatically
when the machine is switched on.
2. Information for the Use of Wall Chasers
Please observe the following notes in order to reduce
the dust emissions occurring while working.
– Use only the combinations of wall chaser and vacuum
cleaner recommended by FELISATTI. Other combinations
can lead to insufcient dust collection and separation.
– Observe the operating instructions of the vacuum
cleaner for maintenance and cleaning of the vacuum
cleaner, including the lter. Empty dust collection containers
immediately once full. Clean the lters of the vacuum
cleaner regularly and always insert the lters completely
into the vacuum cleaner.
– Only use vacuum hoses as intended for by FELISATTI.
Do not manipulate the vacuum hose. When rocks or chunks
Wall Chaser
SD230/2200 SD230/2600E
Rated voltage
V~
230
Rated frequency
Hz
50-60
Rated power
W
2200 2600
No load speed
min
-1
4500 6600
Max. diameter for diamond cutting discs
mm
230
Mounting bore
mm
22.2
Slot depth
mm
20-65
Slot width
mm
3-41
Weight according EPTA-Procedure 01/2003
kg
9.8 9.9
