 The motor must be allowed to come to completely stop

before being put to one side between uses.

 The milling heads should be protected from impacts

and knocks.

 The milling heads should not be touched after use

because they could cause serious burns.

BRIEF DESCRIPTION

This machine is designed for use with rotary milling

heads for milling slots, edges, profiles and rough-edged

holes, from a firm base, in wood, synthetic and light

construction materials.

BEFORE USING THIS TOOL

Make sure the mains voltage is correct: it must be the

same as that on the specification label. Machines with

230-V can also be connected to a 220-V mains supply.

Start the machine by turning the switch A to position

"ON". To switch off, do the same in reverse.

Constant electronic performance and speed adjustment

The built-in module enables soft start and for the rated

speed to be maintained practically constant until the

rated power is reached.

The electronic speed regulator enables the speed to

be set to different positions from 1 to 6. The most

appropriate speed should be selected according to the

part to be polished.

PRECAUTION: The speed regulator can only be turned

to position 6 and then be returned to position 1. It must

never be forced beyond 6 or 1, since this could cause

damage to the machine.

MILLING HEAD SELECTION AND INSTALLATION

1.1. Milling head selection

Depending on the materials to be worked, the following

milling head qualities may be selected:

 High-performance, fast-cutting steel milling heads

(HSS): suitable for soft materials, such as soft woods

and plastic.

 Milling heads with hard metal blades (HM): suitable

hard and abrasive materials, such as hard woods and

aluminum.

WARNING! The milling heads that are employed must

be officially approved in accordance with the maximum

revolutions defined for the respective tools. The milling

head shaft diameter should match the inside diameter of

the tool-holder (locking clip).

1.2. Milling head installation

WARNING! The mains cable must be removed from the

socket before any adjustments are made to the machine.

It is recommended that protective gloves be worn when

installing or removing milling heads.

- To install the milling head, press the spindle lock of

shaft B until it coincides with the shaft planes.

- A 17-mm spanner should be used to loosen clip fixing

nut D in an anticlockwise direction.

- Insert the milling head so that the shaft enters the clip

by a minimum of 20 mm (shaft length).

- Tighten the clip fixing nut D with the spanner and

release the clip-carrier shaft support lever B.

PRECAUTION: Do not tighten clip fixing nut D without a

milling head inserted into the clip.

ADJUSTING MILLING OPERATION DEPTH

WARNING! The milling operation depth adjustment

must only be performed with the machine switched off.

The milling operation depth may be adjusted according

to the work to be carried out.

The machine is fitted with a depth stop E, the upper

surface of which is used in conjunction with the gradu-

ated scale M fine control of the milling operation depth.

For deep cutting operations, it is recommended that

several passes be made, with a reduced chip thickness.

Operate the fixing lever H and slowly push the upper

section of the machine against the depth stop E. Lock

the machine by releasing the fixing lever H.

Loosening the locking wing nut G will release the depth

stop E, facilitating simple stop adjustment.

Fixing lever H should be pressed to immobilize the

machine at a determined working height.

With the stepped stop F it is possible to perform the

milling operation in three stages. To start, adjust the

milling depth to the lowest position of stepped stop F.

Then the milling operation can be carried out at the

higher positions.

PRECAUTION: For large diameter cuts, it is recom-

mended that the depth is set to minimum and to con-

tinue cutting in stages.

When commencing the work, the milling head should be

slowly entered until the desired depth is obtained and

then allowed to advance, always supporting the machine

with two hands.

OPERATING INSTRUCTIONS.

PRECAUTION: The machine should always be un-

plugged before making any adjustments to the machine.

WARNING! The actual milling operation should always be

made in the direction opposite to the milling head rotation

direction. Advancing the machine in the opposite direction

could cause it to rebound and lead to an accident.

1.1. Milling

1. The milling depth should be adjusted in accordance

with the previous description.

2. Switch on and place the machine over the work

piece, firmly held in place.

3. Carry out the milling operation with a uniform ad-

vancing movement.

4. On completing the milling operation, push the upper

section of the machine upwards and switch it off.

1.2. Milling with parallel stop

To install the parallel stop and with the guide rods in the

base plate P and held in place with the wing screws V

according to the required measurement.

Once both wing screws V have been loosened, the

parallel stop can be re-adjusted using fine adjustment T.

Adjust the desired length with the divisions with inches

and millimeters marked on the side stop I.

Stop strip S may be used to increase the parallel stop

contact surface.

DUST EXTRACTION

WARNING! Always make sure that the tool is switched

off and unplugged before fitting or removing any dust

extraction device.
