12
Symbols
Warning of general danger
Wear ear protection!
Wear protective goggles!
Wear a dust mask.
Read the Operating Instructions/Notes!
1 Intended use
The routers are designed for routing wood, plas-
tics and similar materials.
Aluminium and plasterboard can also be proc-
essed with corresponding cutters such as are
listed in the Festool catalogues.
The user is liable for damage and injury
resulting from incorrect usage!
2 Safety instructions
2.1 Rules
WARNING! Read all safety warnings and
all instructions. Failure to follow the warn-
ings and instructions may result in electric shock,
fi re and/or serious injury.
Save all warnings and instructions for future
reference.
The term „power tool“ in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
2.2 Tool-specifi c safety rules
- Hold power tool by insulated gripping surfaces,
because the cutter may contact its own cord.
Cutting a „live“ wire may make exposed metal
parts of the power tool “”live”” and could give
the operator an electric shock.
- Use clamps or another practical way to secure
and support the workpiece to a stable platform.
Holding the work by your hand or against the
body leaves it unstable and may lead to loss of
control.
- Do not exceed the maximum speed specifi ed on
the tool and/or keep to the speed range.
- The clamping collet should only be used to
clamp tools with a shank diameter appropriate
for the collet.
- Check that the cutter is fi rmly fi tted and runs
freely.
- The clamping collet and union nut must show
no signs of damage.
- Cracked or distorted cutters must not be
used.
Wear suitable protection such as
ear protection, safety goggles, a
dust mask for work which gener-
ates dust, and protective gloves
when working with raw materials
and when changing tools.
- Festool electric power tools should only be
installed in work benches specially designed
by Festool. The electric power tool may become
unsafe and cause serious accident if installed
in benches from other manufacturers or self-
manufactured work benches.
3 Noise and vibration information
The typical values determined in accordance with
EN 60745 are:
Router
Technical data OF 1010 EBQ OF 1010 EQ OF 1010 Q
Power 1010 W 1010 W 720 W
Speed (no load) 10000 - 24000 rpm 9500 - 23000 rpm 26500 rpm
Quick height adjustment 55 mm 55 mm 55 mm
Fine height adjustment 8 mm 8 mm 8 mm
Drive shaft connection of the spindle
M16x1.5 M16x1.5 M16x1.5
Router diameter max. 35 mm max. 35 mm max. 35 mm
Weight (excluding cable) 2.7 kg 2.7 kg 2.7 kg
Degree of protection
/ II / II / II
The specifi ed illustrations can be found at the beginning of the operating instructions.
