Thermowarm TWT/TWTC

5

GB

Thermovarm is a small and neat ribbed pipe

radiator. It is especially suitable for spaces

where relatively high output is needed but

there is limited space. The front plate is re-

movable, which makes the radiator easy to

clean. TWT has sides of grey thermo plastic

and either a lacquered or ﬂocked front plate.

TWTC has sides of black thermo plastic and

front plate, inner sides, brackets and elements

are in lacquered corrosion proof design.

Mounting

The radiator is attached to the wall with four

screws. There is a template for placing the

screws on the bottom of the carton. Stick a

sharp instrument through the marks on the

carton to mark where to place the screws.

The two upper holes are “keyholes”. See

sketches on page 2. Electrical connection of

TWT100 and TWT200 must be permanent

and done by an authorized electrician.

Versions

• TWT100 is equipped with thermostat and

output switching 0-1/1. 230V or 400V.

Protection class IP44.

• TWT300 is equipped with thermostat, cord

and plug. Available in 230V only.

Protection class IP 21.

• TWT200 is equipped with thermostat and

output switching 0-1/1. 230V or 400V.

TWT200 has ﬂocked front plate and is

approved for use in children’s rooms and in

household personal hygiene rooms where

there is a maximum temperature of 60°C.

Protection class IP44.

• TWTC is equipped with thermostat, cord

and plug. Available in 230V only. TWTC is

in corrosion proof design.

Protecion class IP54.

Thermostat

The thermostat is of the capillary tube type

and adjustable between 0-35°C.

TWT:

A Celsius scale is marked on the side of the

thermostat dial. The dial is on the right side

of the heater.

The scale of the thermostat dial can be tur-

ned to calibrate the thermostat to the room

temperature in question.

TWTC:

The thermostat is protected under a threaded

lid on the right side of the heater. The lid can

be removed by a screwdriver. See sketch on

page 2 for thermostat setting. The thermo-

stat is set by turning the notch to the desired

temperature.

Overheat protection

TWT:

The overheat protection can be reset by

pushing the button on the right end plate of

the heater.

TWTC:

The overheat protectionis protected under a

threaded lid on the right side of the heater.

The lid can be removed by a screwdriver. The

overheat protection is reset by pushing the

button.

Cleaning

Remove dust with a vacuum cleaner or a soft

brush.

For the 200 series with ﬂocked front plate:

The surface can be washed with mild soap

solution or carpet foam. Remove spots with

chemically pure petrol. Avoid strong solvents

such as acetone and similar.

Safety

This appliance is not intended for use by

persons (including children) with reduced

physical or mental capabilities, or lack

of experience and knowledge, unless they

have been given supervision or instruction

concerning use of the appliance by a per-

son responsible for their safety. Children

should be supervised to ensure that they do

not play with the appliance.

Mounting and assembly
