Omperator's anual

www.fubag.ru

--2

2. Technical specifications

The manufacturer reserves himself the right to make the manual's content or function change

without any preliminary notification of the users.

3. Description

Fan heater incorporates a thermostat and a self-resetting thermal cut-out to control the heating

elements. The thermostat feels the air temperature and controls the surrounding temperature. The

fan motor is not controlled by thermostat and it keeps on working when the thermostat cuts off the

heating element. The self-resetting thermal cut-out will switch off the heater to ensure the safety

when overheating.

. Handle

Thermostat

Switch knob

Front cover

Frame

Adjustment knob

Rear cover

Motor

Function selector with four power

settings

Thermostat dial

3. Power indicator

Model SIROCCO Keramik

20M

SIROCCO Keramik

33M

SIROCCO Keramik

50T

Power rating, kW 1,0/2,0 1,5/3,0 3,3/5,0

Flow, м

/h 158 217 423

Voltage, V 220 380

Max c kWonsumed power, 2,0 3,0 5,0

Rated current, А 9,0 13,6 7,6

The environment temperature range, °С -10°…+40°

Relative humidity, % 60% at 20°С

Dimensions (LxWxH), мм 160х210х217 210х265х293 235х300х343

Weight, kg 1,7 2,9 4,3
