Omperator's anual

- 3 -

4. Connection and operation

- The equipment has protective coating. Flush the equipment with the proper solution before use.

- The gun is designed for operation with dry and clean air. Taking into account compressed air may

contain damp and foreign mixtures causing corrosion and untimely tear and wear of the pneumatic

tool it is recommended to use a filter in the air line (moisture and oil separator). The filter is necessary

to be installed as closer to the aerograph as it is possible.

- The pressure in the air channel is to be maintained up to 3 - 4 5 bars. Too low or too high pressure

may cause the tool damage and make the quality of cleaning worse.

- Check and if necessary change damaged and worn parts of the tool.

- Make sure the cocking piece and the nozzle are in good working condition.

- Connect the air hose to the air inlet. The recommended hose size is 8 mm.

- Make sure the connections with the air inlet; the tank and the top (for model 110115) are tightened

safely.

- Prepare the abrasive. The tool can operate with the abrasive with the particles of 1 6 mm diameter

and less.

- For model 110115 fill up the tank with the abrasive. Do not fill up the tank with less than 2/3 of its

volume.

- For model 110116 place the tip of the intake hose in the tank with the abrasive to 2/3 from the length

of the intake tip.

- Press the startup cramp to begin cleaning.

- Hold the gun perpendicularly to the atomized surface. The slopes may cause irregular cleaning.

- The recommended distance of the atomization is 200-300 mm.

- Do not forget to switch off the compressed air intake after operation.

5. Maintenance

- Disconnect the gun form the compressed air system.

- Remove the unused abrasive into the proper container and clean the gun and the tank (model

110115). Blow the gun through with the compressed air.

- Remove the cover of the nozzle and clean it.

- Make sure the nozzle is clean and not damaged. The new nozzle of 10 (model 110116) and 6

(model 110115) diameter. Change the nozzle when it is worn more than 1 5 mm and in case the

abrasive intake is reduced immensely.

- The stud and the air valve are to be lubricated every time before operation.

mm ,
