Omperator's anual

--6

TIG m with functionode LiftArc

The DC TIG welding requires a protective gas (argon).

Follow the steps as below :

- Connect the earth clamp on the positive (+) pole.

- Connect a TIG torch with valve on the negative (-) pole.

- Connect the pipe of the gas bottle and adjust the flow.

- Select the TIG position with the selector .

-Adjust the wished current (display ) using the keys and .

- To boot: touch the electrode on the welding part; raise the electrode 2 to 5 mm of the part to be

welded.

- aise the torch for a quick gesture, do not cut the gas only after electrode cooling.

145

7 aintenance.M

- Regularly blow the welding machine with the pressed air through the ventilation inlets

Refer all servicing to qualified personnel.

Disconnect the generator and wait until the ventilator stopped before working on the unit.

Inside the device, voltages and current are dangerous.
