EN
EN - 5
Switching off the appliance
- Push the switches (13, 14 Fig. 9) to the
“0” position to stop the device; the lights,
if any on the switches, will go off.
- Remove the plug (12 Fig. 8) from the
electrical socket.
- Wind up the cable (15 Fig. 10) and hook
it onto its housing (16 Fig. 10).
CLEANING AND
MAINTENANCE
DANGER:
Before performing any maintenance op-
eration, unplug the appliance from the
electrical socket.
Emptying the recovery tank
- Release the lever (1 Fig. 1) and remove
the top (2 Fig. 2) along with the engine.
- Remove the filter bag (3 Fig. 3) and clean
it as described above.
Residues after the use of the vacuum
cleaner
- Empty the contents of the tank into a
trash bag.
Residues after the use of the liquid vac-
uum
- Place it on the top of a drain and empty
the liquid in the recovery tank (17 Fig.
11).
- Clean the inside of the tank with running
water and then re-install everything doing
the opposite of the disassembly.
For machines equipped with drain
hose
- Release the exhaust tube (18 Fig. 12)
from its base.
- Unscrew the button (19 Fig. 12), re-
move the cap (20 Fig. 12) of the ex-
haust hose (21 Fig. 12) and drain the
liquid in the recovery tank (22 Fig.
12).
Daily cleaning
Checking and cleaning the TNT
(polyester) filter
- Release the levers (1 Fig. 1) and remove
the cover (2 Fig. 2) complete with motor.
- Remove the polyester (3 Fig. 3) filter.
- Clean the filter (Fig. 13) from the inside
out with a blast of air; the filter can be
washed (Fig. 13) in warm water and must
only be replaced once it is completely
dry. If it is too dirty, replace it.
- Reassemble all the parts by following the
dismantling process steps in the reverse
order.
Cleaning the appliance
- Clean the unit body with a cloth damp-
ened with water or a mild detergent.
- Remove the top, as described above and
clean the inside with running water and
then empty it, as indicated above.
Replace everything doing the opposite of
the disassembly.
DANGER:
Do not wash the appliance using jets of
water.
NOTE:
Make sure the tank is completely dry before
using your device as a dust vacuum.
Periodic checks
Checking the floater
- Remove the top as shown above.
- Check If the floater (23 Fig. 14) is In
good condition and if it moves freely in its
space.
