Electric convector

4. CONNECTING TO THE MAINS





technical data of the device.

3. Convector when connected to the plug must comply with applicable electrical codes.

4. Electric outlet must be properly grounded. The receptacle must be rated for at least 10A.

Electrical plug and socket must always be kept dry to prevent electrical leakage. Regularly check





the power cord, check with the hand , whether the plug is not heated.



to poor electrical contact replace the socket with help of a specialist.

3. WALL INSTALLATION

1. Uncover the original packaging and carefully remove device from it.

2. Remove any foam seals on the edges of the device and release it from polyethylene.

3. Determine the location for the convector in compliance with the minimum distance from the





5. Drill holes in the wall of the required diameter, insert the dowels*, tighten the set screws*.

6. Attach the mounting brackets to the cover of the unit with the mounting screws.

7. Perform installation on the wall convector, setting the screws installed in the wall brackets with

the holes that are installed on the device.



* May not be included in delivery set

Installing castors on the convector

1. Remove the two support legs from the packaging of the convector.

2. Turn the unit so that its bottom was in easy access.

                   



4. Tighten the screws in the existing holes.

Fig. 4
