10.

Gas ceramic heater

ATTENTION!

Do not smoke during replacement of the cylinder.



gas cylinders in a separate well-ventilated room far from combustible



high-rise buildings, cellars, garrets.

Start

1. Slowly unscrew the check valve of the gas cylinder.

2. Press and slowly turn the gas control knob on the control panel to « » position. Keep the gas

control knob pressed for 20-30 seconds. At the same time, press the piezo-ignition button several

times, until the pilot lights up. Every time you press the piezo-ignition button, you can hear a

loud click and see a spark on the piezo-ignition electrode. Continue keeping the gas control knob



3. Leave the gas control knob in this position at least for 5 minutes for stable ignition of the 1st

heating stage. The pilot and central element of the ceramic burner should be alight. This position

corresponds to the heat power of 1.4 kW.

4. To change the heating stage, slightly press the gas control knob and slowly turn it anticlockwise

until locking in « » or « » position, which corresponds to the heat power of 2.8 kW and

4.2 kW.



Shutdown

1. Press the gas control knob and turn it to « » position. The pilot and central element of the

ceramic burner should be alight.

2. Screw the check valve on the gas cylinder clockwise up to the stop.

3. If you do not plan to use the heater in the nearest time, disconnect the gas cylinder from the

reducer. Remove the gas cylinder to the storage place according to the recommendations and



Gas cylinder replacement



2. If it is necessary to replace an empty gas cylinder, shut gas screwing the gas check valve on the

cylinder clockwise up to the stop.

3. Remove the cylinder clamp and take the cylinder out of the heater body.

4. Remove the gas pressure reducer from the cylinder unscrewing its cap nut.

5. Connect and install a full gas cylinder as indicated in Section

6. Preparation for work.
