Electric convector

Package contents

1. Convector - 1 pc.

2. Supporting feet - 2 pc.

3. Wall mounting set - 1 pc.

4. Operating manual and warranty card - 1 pc.



Table 1

H-HV1-10-

UI562

H-HV1-15-

UI563

H-HV1-20-

UI564

Nominal power consumption

W 1000 1500 2000

Rated current А 4,5 6,8 9,1

Rated voltage V/Hz ~220/50 ~220/50 ~220/50

Protection class IP24 IP24 IP24

Electric protection class Class I Class I Class I

Weight Kg 5,4 6,6 7,6

Dimensions mm 613x88x450 770x88x450 890x88x450

Appearance

1. Front panel

2. Air outlet

3. Rear panel

4. Thermostat switch

5. Power switch

6. Indicator

7. Handle

8. Water box

9. Wheels assembly

Fig. 1
