English

CLEANING THE UNDERSIDE OF THE MOWER DECK

1. Raise the mower to full height.

2. Connect a female water hose connector (not supplied)

to the male hose connector on the mower deck.

3. Turn on the water supply.

4. Start the mower and run at full revolutions, but do not

engage the self-propel bail.

5. Run the engine in place for approximately 30 seconds.

6. Shut off the engine.

7. Turn off the water supply.

8. Inspect the underside of the mower deck for cleanliness,

and repeat the cleaning procedure if desired.

LUBRICATION

All of the bearings in the product are lubricated with a

suf¿ cient amount of high grade lubricant for the life of the

product under normal operating conditions. Therefore, no

further bearing lubrication is required.

WARNING

Always protect hands by wearing heavy gloves or

wrapping the cutting edges of the blade with rags

and other material, or both, when performing blade

maintenance. Contact with the blade could result in

serious personal injury.

REPLACING THE CUTTING BLADE

See figure 12.

When making adjustments, be careful not to entrap your

¿ ngers between moving blades and ¿ xed parts of the

product.

For best results, the mower blade must be kept sharp.

Immediately replace a bent or damaged blade.

WARNING

Only use replacement blades approved by the

manufacturer of the product. Using a blade not approved

by the manufacturer of the product is hazardous and

could result in serious injury, damage to the product, and

will void your warranty.

WARNING

Drain the fuel first before tilting the product to replace

the blade.

1. Stop the engine and disconnect the spark plug wire.

Allow the blade to come to a complete stop.

2. Turn the product on its side (air filter facing up).

3. Wedge a block of wood between the blade and the

mower deck to prevent the blade from turning.

Ɣ Installing: See figure 12a.

Ɣ Removing: See figure 12b.

NOTE: Do not wedge the block of wood between the

blade and the plastic cover.

4. Using a 16 mm wrench or socket (not provided), loosen

the blade bolt by turning the bolt in a counterclockwise

direction as viewed from the bottom of the product.

5. Remove the blade bolt, spring washer, and blade.

6. Place the new blade on the shaft. Make sure it is

installed with the curved ends pointing up toward the

mower deck and not down toward the ground.

7. Replace the spring washer, and blade bolt on the shaft.

Finger tighten the bolt by turning in a clockwise direction

as viewed from the bottom of the product.

NOTE: Ensure all parts are replaced in the exact order

in which they were removed.

8. Torque the blade bolt down using a torque wrench (not

provided) to ensure the bolt is properly tightened.

9. The recommended torque for the blade bolt is 40 – 45

Nm.

NOTE: Do not sharpen the blades; replace with new

item. Blades need to be properly balanced to avoid

damage and personal injury.

CLEANING THE AIR FILTER

See figure 13.

For proper performance and long life, keep the air ¿ lter

clean.

1. Remove the air filter cover by pushing down the latch

while gently pulling out the cover.

2. Remove the air filter and clean it in warm soapy water.

Rinse and let dry completely.

3. Apply a light coat of engine oil to the air filter, then

squeeze it out using an absorbent cloth or paper towel.

4. Reinstall the air filter into the air filter base.

5. Replace and secure the air filter cover.

NOTE: The filter should be replaced annually for best

performance.

FUEL CAP

WARNING

A leaking fuel cap is a fire hazard and must be replaced

immediately.

The fuel cap contains a non-serviceable ¿ lter and a

check valve. A clogged fuel cap will cause poor engine

performance. If performance improves when the fuel cap

is loosened, check valve may be faulty or clogged. Replace

fuel cap if required.

CHANGING THE ENGINE OIL

See figure 14.

Ensure the fuel tank is completely empty before tipping the

unit over; otherwise, fuel will leak out.
