10
ENGLISH
(Original instructions)
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regular cleaning.
Warning! Before performing any maintenance, switch off
and unplug the tool.
• Regularly clean the ventilation slots in your tool using a
soft brush or dry cloth.
• Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
Replacing the drive belt (fig. I)
• Loosen the screws (15) and remove the cover (16).
• Remove the old drive belt.
• Place the new belt (17) over the pulleys. Place the belt
over the large pulley (18) first, then over the small pulley
(19), whilst manually rotating the belt steadily.
• Put the cover back in place and tighten the screws.
Motor brush inspection and replacement
(fig. J)
Brushes should be regularly inspected for wear.
• Remove brush cap (22). The brushes should slide freely
in brush box. If brushes are worn down to .3" (8mm) they
should be replaced.
To reinstall, push new brush back into brush box. If replacing
existing brush, maintain same orientation as when removed.
Replace the brush cap (do not overtighten).
Mains Plug Replacement
If a new mains plug needs to be fitted:
• Safely dispose of the old plug.
• Connect the brown lead to the live terminal of the new
plug.
• Connect the blue lead to the neutral terminal.
• If the product is class l (earthed), connect the green /
yellow lead to the earth terminal.
Warning! If your product is class ll double insulated (only 2
wires in the cord set), no connection is to be made to the
earth terminal.
Follow the fitting instructions supplied with good quality
plugs.
Any replacement fuse must be of the same rating as the
original fuse supplied with the product.
Specification STPP7502
Input voltage Vac 220-240
Power input W 750
No-load speed min-1 16,500
Planing width mm 82
Planing depth mm 1.6
Rebating depth mm 12
Weight kg 2.9
Technical Data
