7.2 Geka Coupling/C Coupling Adapter

7.3 NFB Wet Filter Bag

order number 42 05 92

(3 pieces = 1 set)

– 2-layer, water- and tear-proof

➙ Excellent for sludge extraction

applications (such as wet drilling, wet grinding and wet

cutting stones, concrete or masonry and separating

sludge and liquid).

7. Special Accessories

order number 19 37 00

Consisting of:

1 vacuum hose Ø 49 mm, 5 m long, 1 outlet hose

Ø 33 mm, 10 m long, 3 plastic suction pipes, per 48 cm

long, Ø 49 mm, 1 plastic suction pipe, 48 cm long with

secondary air hole, Ø 49 mm (refer to figure)*

1 course dirt nozzle

1 pond vacuum nozzle,

adjustable

1 nozzle adapter of 49 mm

to 35 mm hose system

The pond accessories are

supplied in a robust container

box on 2 castors.

Dimensions 800 x 400 x 320 mm, volume 75 l.

7.1 TSZ Pond Accessories

6.3 Pump Vacuum Cleaner Performance Values

(Combination of vacuum cleaner + pump)

UThe pump vacuum cleaner should always be higher

than the water level to guarantee correct functioning.

*Description of the pipe

with the secondary air

hole

Full vacuuming (100% water)

requires using the pipe with the secondary air hole. The

secondary air hole has to be outside of the water.

If this is not done or if the pipe is not correctly

mounted, the vacuum cleaner might vacuum more

water than the pump can pump off.

The cleaning power may be too low with secondary

air hole when vacuuming normally. In this case, tape

the secondary air hole closed or hold closed with your

finger.

6.2 Wet/Dry Vacuum Cleaner

➙

Refer to the operating instructions for the

wet/dry vacuum cleaner.

order number 42 41 87

For connecting a fire brigade

hose to the 10 m runoff hose

of the pump vacuum cleaner.

max. 6 m

max. 1,5 m

max. 6 m

ca. 5–8 m

max. 3 m

maximum 50 m of pumping width

Operation:

full pumping (100% water)

Operation: water-air mixture

For the special notice regarding the

use of the fuse, see page 82
