Connecting The DSL-210 USB
ADSL Modem to Internet
If you are instructed to use a split line style filter you must install the
device between the Modem and the phone jack. Use standard telephone
cable with standard RJ-11 connectors. The splitter has three RJ-11 ports
used to connect to the wall jack, the Modem and if desired, a telephone or
telephone device. The connection ports are typically labeled as follows:
The diagram below illustrates the proper use of the split line style filter.
