www.timberk.com • electric oil filled radiator

IMPORTANT!

1. Switch on and operate the radiator only when upright (with

wheels below and control elements above). Any other position

may cause a dangerous situation and result in failure of the oil-

filled radiator or damage of property and the manufacturer will

consider this as a non-warranty case.

2. Do not switch the radiator on, if roller wheels are not installed.

1. Read section «Important precautions» carefully unless you already did it.

2. Connect the unit’s power cord to an electric outlet, observing all of the

abovementioned precautions. Remember that you can connect the unit to

electric mains only if the rotating power regulator is in OFF position (switched

off), i.e. the knob is rotated against the stop counterclockwise.

3. It is also preferable to turn the temperature regulating knob against the stop

counterclockwise. Then you can connect the unit to electric mains.

4. Set the unit’s power regulator (knob) to position I, II or III (corresponds to low,

normal and maximum power of unit’s operation). Remember that the higher the

power you choose, the faster the unit heats the air. But at a low power you save

electric power and reduce the load on your electric mains.

5. After you chose the desired operating power in accordance with your

individual preferences, you have to choose the desired heating temperature.

Turning the thermostat knob clockwise (from MIN position towards MAX

position), you thus adjust the temperature mode you need. Since the moment

you choose the temperature mode (provided one or another power mode is

activated see item 4) the oil filled radiator will start to operate.

6. During the first minutes of radiator’s operation you may fell a slight smell of

burning. It may be caused by dust on the unit; it will soon disappear. If necessary,

you can perform a preliminary preventive cleaning of the unit, following rules, set

forth in this manual and observing «Important precautions».

7. When the room temperature will reach the desired level, you should slowly

turn the temperature regulator’s knob counterclockwise (towards MIN). You will

hear a click of the thermostat turning off, and the light on the control panel will

go out. Now the room temperature will be maintained at the chosen level.

7. UNIT OPERATION RULES AND PROCEDURE

IMPORTANT!

For the unit to operate normally, the level of voltage in

electric mains must be sufficient in strict compliance

with the technical parameters indicated on the unit.

Carefully study the technical label, as well as all labels

with special warnings, attached to the unit’s surface.

1. Remember that you must clean the unit regularly to remove dust from the

surface of heating sections. Dust and dirt on the unit’s surface have a negative

effect on the unit’s operational efficiency, in some cases a smell of burning dust

can cause a headache and nausea, as well as other negative health effects.

Also a dirty unit cannot operate 100% effectively, temperature parameters of

the room heating can be disrupted.

2. Prior to preventive cleaning of the unit, you must switch off the unit, unplug

it from electric mains (see «Important precautions») and let the unit cool down.

3. Clean the unit’s sections and other surfaces with a soft, slightly damp duster/

cloth. The cloth must not leave fluff on the unit’s surface.

4. It is not recommended to use detergents, including materials containing

abrasive elements.

5. During cleaning, please, do not damage the unit’s surface by sharp objects

(hard sponge, polishing paper, etc). Scratches on the painted surface can result

in rusting.

Switch on and use the unit again only having carried out all «Important

precautions»; also make sure that the unit’s surface is absolutely dry.

8. CLEANING AND MAINTENANCE OF THE UNIT

8. If you need to reduce the room temperature, turn the thermostat knob

counterclockwise. Also you can lower the unit’s operating power (I or II).

9. If you need to raise the room temperature, turn the thermostat knob

clockwise (maximum possible position MAX indicator). Also you can raise the

unit’s operating power (II or III).
