www.timberk.com • electrical storage water heater
12
11. WIRING DIAGRAM
Thermal stoper
Heating element
indication
lampe
Thermostat
L
N
E
Q
Q
Fig. 10
IMPORTANT!
To ensure reliable operation and safe use of the
water heater, prior to the first activation check if it is
correctly connected to 230V alternating voltage mains.
The water heater to be connected must be securely
connected to an earth circuit of your electric mains.
NOTE:
Technical and any other characteristics of the
appliance can be revised.
Such changes may be introduced without warning and
prior notice to the consumers.
The manufacturer shall not be liable for changes in the
appliance’s wiring diagram that may be implemented
without notice to the consumers.
The water heater should be disposed upon the end of life. You can obtain
detailed information on water heater disposal from a representative of local
authorities.
Timberk disclaims any liability for possible damage, directly or indirectly
caused by Timberk products to people, pets, property in case if it occurred
as a result of failure to observe rules and conditions of operation, unit’s
installation, deliberate or careless actions of the consumer or third parties.
The tank water heater is not intended to be used by children, old or disabled
people without supervision. Make sure to use the water heater carefully,
do not switch between modes abruptly, closely follow recommendations,
set forth in this operation manual. Children nearby the fan heater must be
supervised by adults and must never use the unit playing games.
Guarantee card is enclosed in the product package!
13. DISPOSAL
12. TRANSPORTATION AND STORAGE
CONDITIONS
Temperature
requirements*
Humidity
requirements*
Transportation and
storage
From -30° to +50°
From 15% to 85%
(without a condensate)
We are exploring new technologies and we constantly improving the quality
of our products. That’s why specifications, design and accessories are
subject to change without any specific notice.
14. SERIAL NUMBER AND PRODUCTION DATE
Serial number, production month and year are included in ID LINE product
code. Sticker with ID LINE code is pasted on product surface. Month and
two last numbers of year is putted after symbol “-“.
